C-Purlin made from hot rolled steel sheet. It stands out for its durability and resistance. It is used to make structures such as ships, buildings, factories, bridges. They are designed to withstand heavy loads and are an essential material for constructions thanks to their properties.
The C-purlin is a C-shaped profile manufactured from hot-rolled steel sheet, distinguished by its durability and strength. It is used for the construction of structures such as industrial buildings, warehouses, factories, and bridges. C-purlins are designed to support heavy loads, making them a fundamental material in construction due to their mechanical properties.
The C-purlin is a C-shaped profile made from hot-rolled steel. At Serviacero Comercial, we manufacture these profiles to match the required project length. They are available in three finishes: painted, black, and galvanized. Additionally, they can be produced with perforations (punched, drilled, or stamped) or without them, and in gauges ranging from 9 to 16. This makes C-purlins an essential material for structural projects.
In summary, C-purlins provide a combination of strength, versatility, ease of installation, and durability, making them widely used in the construction and structural engineering industries.
We manufacture punched C-purlins in gauges 9 to 16, with lengths customized to your project, and have production capacity up to 14 meters, in painted, black, and galvanized finishes, in both commercial and high-strength grades.
| Standard C. Commercial ASTM A 500 | Standard A. Strength ASTM A 500 GR C | ||||||
|---|---|---|---|---|---|---|
| "C" Purlin | ||||||
| A x B x C (inches) | Caliber | thickness (inches) | Inventory | standard length (meters) | pieces per pack | kilogram per meter |
| 3 x 1.5 x 0.5 | 12 | 0.1046 | * | 6 | 48 | 3.21 |
| 3 x 1.5 x 0.5 | 14 | 0.0747 | Painted | 6 | 48 | 2.36 |
| 3 x 1.5 x 0.5 | 16 | 0.0598 | * | 6 | 48 | 1.93 |
| 4 x 2 x 0.75 | 10 | 0.1345 | * | 6 | 48 | 5.76 |
| 4 x 2 x 0.75 | 12 | 0.1046 | * | 6 | 48 | 4.54 |
| 4 x 2 x 0.75 | 14 | 0.0747 | Painted | 6 | 48 | 3.30 |
| 4 x 2 x 0.75 | 16 | 0.0598 | * | 6 | 48 | 2.69 |
| 5 x 2 x 0.75 | 10 | 0.1345 | * | 6 | 48 | 6.44 |
| 5 x 2 x 0.75 | 12 | 0.1046 | * | 6 | 48 | 5.07 |
| 5 x 2 x 0.75 | 14 | 0.0747 | Painted | 5 | 48 | 3.68 |
| 5 x 2 x 0.75 | 14 | 0.0747 | Painted | 6 | 48 | 3.68 |
| 5 x 2 x 0.75 | 16 | 0.0598 | * | 6 | 48 | 2.99 |
| 6 x 2 x 0.75 | 10 | 0.1345 | * | 6 | 48 | 7.12 |
| 6 x 2 x 0.75 | 12 | 0.1046 | Painted | 6 | 48 | 5.6 |
| 6 x 2 x 0.75 | 14 | 0.0747 | Painted | 6 | 48 | 4.07 |
| 6 x 2 x 0.75 | 16 | 0.0598 | * | 6 | 48 | 3.29 |
| 7 x 2.75 x 0.75 | 10 | 0.1345 | * | 7 | 36 | 8.83 |
| 7 x 2.75 x 0.75 | 12 | 0.1046 | * | 7 | 36 | 6.93 |
| 7 x 2.75 x 0.75 | 14 | 0.0747 | Painted | 7 | 36 | 5.01 |
| 7 x 2.75 x 0.75 | 16 | 0.0598 | * | 7 | 36 | 4.05 |
| 8 x 2.75 x 0.75 | 10 | 0.1345 | * | 8 | 36 | 9.51 |
| 8 x 2.75 x 0.75 | 12 | 0.1046 | Painted | 8 | 36 | 7.4 |
| 8 x 2.75 x 0.75 | 14 | 0.0747 | Painted | 8 | 36 | 5.58 |
| 8 x 2.75 x 0.75 | 16 | 0.0598 | * | 8 | 36 | 4.36 |
| 10 x 2.75 x 0.75 | 10 | 0.1345 | * | 10 | 24 | 10.88 |
| 10 x 2.75 x 0.75 | 12 | 0.1046 | Painted | 10 | 24 | 8.5 |
| 10 x 2.75 x 0.75 | 14 | 0.0747 | Painted | 10 | 24 | 6.15 |
| 10 x 2.75 x 0.75 | 16 | 0.0598 | * | 10 | 24 | 4.96 |
| 12 x 3.5 x 0.875 | 10 | 0.1345 | * | 12 | 20 | 13.45 |
| 12 x 3.5 x 0.875 | 12 | 0.1046 | Painted | 12 | 20 | 10.52 |
| 12 x 3.5 x 0.875 | 14 | 0.0747 | Painted | 12 | 20 | 7.54 |
| 12 x 3.5 x 0.875 | 16 | 0.0598 | * | 12 | 20 | 6.11 |
| "C" Purlin special measures | ||||
|---|---|---|---|---|
| Height "A" (inche) | Flange "B" (inche) | Lip "C" (inche) | Inventory | thickness |
| 3 - 14 | 1.5 | 0.5 | * | 0.06 - 0.1 |
| 4 - 14 | 2 - 2.5 | 0.5 - 0.75 | * | 0.06 - 0.14 |
| 6 - 14 | 2 - 4 | 0.5 - 0.75 | * | |
| 2.75 - 4 | 0.5 - 0.86 | * | ||
| 3 - 4 | 0.5 - 0.1 | * | ||
| * | special manufacturing | |||
| P | painted brown | |||
| Note: For lip 5/8" brows can only be processed in gauges from 0.06" to 0.1 " | ||||
