Losacero 30 is a sheet that is made from galvanized steel, it has a relief design on its surface, it is an ideal material for mezzanines and ceilings, it is a resistant, durable, versatile material, and ideal for supporting loads.
Losacero 30 is a steel sheet manufactured from galvanized steel, featuring embossed patterns on its surface. It is an ideal material for floors and roofs, providing high strength, durability, versatility, and excellent load-bearing capacity.
The Losacero 30 section is designed with surface embossments that primarily provide structural resistance. At Serviacero Comercial, we manufacture it in galvanized finish, available in gauges 18 to 24. Custom sizes can be produced according to project requirements, with lengths ranging from 2.00 m to 12.20 m. Section 30 offers higher load-bearing capacity compared to Section 25.
These advantages make Losacero 30 widely used in the construction industry due to its structural strength, safety, stability, and durability.
Floors and roofs in buildings, industrial warehouses, shopping centers, residential complexes, factories, parking structures, hospitals, schools, and other construction projects.
As a material that can be combined with steel or concrete, Losacero 30 provides a reliable and versatile solution for a wide range of structural applications.
| Losacero 30 | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Standard Specification ASTM A653, SS37 | ||||||||||||
| Theoretical weights table | ||||||||||||
| Caliber | Steel Base | Weight | Superior Compression m+ | Lower compression M- | Shear adm. | Effective width | ||||||
| Ixe + | Sxe+ | M axo+ | Ixe - | Sxe- | Maxo - | Vay (kg/M width) | ||||||
| mm | Inch | kg/ml | kg/m2 | cm4/m | cm3/m | Kg-m | cm4/m | cm3/m | kg-m | |||
| 24 | 0.607 | 0.0239 | 5.8 | 6.04 | 51.07 | 13.01 | 203 | 51.07 | 13.75 | 214 | 1397 | 0.93 |
| 22 | 0.759 | 0.0299 | 7.6 | 8.31 | 67.48 | 18.01 | 281 | 67.03 | 18.82 | 293 | 2206 | 0.93 |
| 20 | 0.912 | 0.0359 | 9.06 | 9.9 | 88.46 | 23.14 | 361 | 83.46 | 24.08 | 375 | 3181 | 0.93 |
| 18 | 1.214 | 0.0478 | 11.96 | 13.07 | 111.32 | 32.76 | 511 | 111.32 | 34.13 | 532 | 4213 | 0.93 |
| SPECIAL MEASURES ON ORDER | ||||||||||||
| CONCRETE, F´C0=2200 KG/CM2, P. VOL. 2400 KG/M3: N=10 | |||||
|---|---|---|---|---|---|
| Caliber | Concrete | Weigth | Clear maximum without propping up | ||
| Description | simple | double | triple | ||
| Inches | cm | kg/m2 | m | m | m |
| 24 0.0239 | 5 | 195 | 1.77 | 2.38 | 2.41 |
| 6 | 218 | 1.7 | 2.29 | 2.32 | |
| 8 | 264 | 1.59 | 2.15 | 2.17 | |
| 10 | 310 | 1.5 | 2.03 | 2.05 | |
| 12 | 356 | 1.42 | 1.93 | 1.95 | |
| 22 0.0299 | 5 | 205 | 2.08 | 2.68 | 2.77 |
| 6 | 229 | 2.00 | 2.58 | 2.66 | |
| 8 | 277 | 1.86 | 2.40 | 2.48 | |
| 10 | 325 | 1.80 | 2.26 | 2.33 | |
| 12 | 373 | 1.78 | 2.13 | 2.20 | |
| 20 0.0359 | 5 | 206 | 2.42 | 3.05 | 3.15 |
| 6 | 230 | 2.32 | 2.93 | 3.03 | |
| 8 | 278 | 2.16 | 2.74 | 2.83 | |
| 10 | 326 | 2.09 | 2.57 | 2.66 | |
| 12 | 374 | 2.06 | 2.44 | 2.52 | |
| 18 0.0478 | 5 | 209 | 2.97 | 3.62 | 3.74 |
| 6 | 233 | 2.85 | 3.48 | 3.60 | |
| 8 | 281 | 2.63 | 325 | 3.36 | |
| 10 | 329 | 2.56 | 3.06 | 3.16 | |
| 12 | 377 | 2.51 | 2.90 | 3.00 | |
| Steel: GR37 | |||||
Losacero 30, being a material that can be combined with steel or concrete as we have mentioned, becomes a reliable option for different applications.
