At Serviacero Comercial we have a laser quality sheet leveling service to match and adjust the surface of this material. We can process hot rolled sheet, pickled sheet, unstripped sheet, cold rolled sheet and coated sheet. Our cutting line is state-of-the-art technology that offers the highest quality standards in the industry.
At Serviacero Comercial we offer the laser quality sheet leveling service, with this process sheets that have any deformation or curvature on the surface are adjusted, straightened and leveled. The goal is to have a flat and uniform material. We can process hot rolled sheet, pickled sheet, unpickled sheet, cold rolled sheet and coated sheet.
Sheet leveling is used in a wide variety of industries, such as construction, automotive, household appliances, white goods and furniture.
• Uniformity: when the sheet is subjected to a leveling process, any undulations that the material may have are eliminated, ensuring a smooth and uniform surface.
• Processing: with this process the sheets are easier to work, cut, weld and shape.
• Precision: a material is obtained with uniform dimensions that certain industries demand.
• Quality: with this process, a material with better quality and aesthetic appearance is obtained that can be used in various industries.
• Durability and resistance: by eliminating the undulations of the material, greater resistance is obtained and it becomes more durable.
• Automotive: they are used for the manufacture of automobile parts such as chassis, bodies or any part where uniformity is sought.
• Construction: we can find applications in the production of roofs, coatings and structures.
• Household appliances: also thanks to its aesthetic finish, the coated sheet can be used to make household appliances such as washing machines, dryers and refrigerators.
• Furniture: for the manufacture of metal furniture, shelves, lockers, filing cabinets, among others where smooth surfaces are sought.
• Energy: for the production of turbine parts, panels, structures, among other components.
In summary, steel sheet leveling is an important process for industries since in this way the quality, durability and functionality of the products made from this material are improved. By eliminating deformities and ensuring uniformity, level steel provides more reliable materials.
| Sheet Leveling | |||
|---|---|---|---|
| Capacity processing | |||
| Sheet Leveling | |||
| Material | Hot Rolled Pickling Sheet, and Without pickling, cold rolled steel sheet and covering. |
||
| Thickness | 0.015” Minimum, 0.0149” Maximum. Nonskid fooring plate: 1.9 mm Max |
||
| Roll weight | 30,000 kgs ( 66,000 lbs) | ||
| Inside diameter | Maximum 30” [760 mm] Minimum 20” [508 mm] |
||
| External diameter | Maximum 78.7” [1980 mm] Minimum 35.4” [914 mm] | ||
| Sheet width | Maximum 74” [1800 mm] Minimum 11.8” [305 mm] | ||
| Length | Maximum 157” [4000 mm] Minimum 9.85” [250 mm] | ||
| Package height | Maximum 29.5” [750 mm] Including pallets / purlin | ||
| Package weight | Maximum 5,000 kg [11,000 lbs] Minimum 24" [ 61 cm] | ||
| Tolerance | - 0 / + 2 mm | ||
| Grade | LE 75 Ksi, RT 90 Ksi Maximum. Thicknesses greater than 3.42 (cal. 10) LE 52 Ksi, RT 65 Ksi Max |
||
| Sheet Meter | Each sheet is identifed with information for the correct traceability of the product. |
||
